LED Designer Post Top
AXPT4118-35WAXPT4118-45WAXPT4118-54W
- Classic design, the product is simple, modern, and elegant. This elegant design will fit the aesthetic of both modern and traditional buildings. Ideal for single and multi-family communities and commercial installations, motels, and hotels. Perfect for landscape, entrances, perimeter, and pool applications.
- Light Distribution: Type 5 - The Type 5 distribution is ideal for general parking and area lighting applications. Intended to be located at or near the center of an intersection or in a large area since it has no beams, but produces a circular distribution with essentially the same candlepower at all lateral angles.
Model data
| Part | Wattage | Base | Lumens | CRI | Energy Savings |
|---|---|---|---|---|---|
| AXPT4118-35W | 35W | E26 | 3,960lm | 80 | =150w PSMH |
| AXPT4118-45W | 45W | E26 | 4,950lm | 80 | =175w PSMH |
| AXPT4118-54W | 54W | E26 | 5,940lm | 80 | =250w PSMH |
Specifications
| Canopy | Aluminum |
|---|---|
| Support Staffs | Fiberglass reinforced plastics. Excellent mechanical strength. |
| Reflector | High Grade Aluminum |
| UL Listing | Wet Location IP65 |
| Socket | 1x E26 Medium Base |
| Lamp | LED Corn (sold separately) |
| Mounting | Fits 3” OD pole |
| Dimensions | 29”H x 25”W |
| Suggested lamps | CORN-360 • 35W - 50K / CORN-360 • 45W - 50K / CORN-360 • 54W - 50K |
Options and ordering
Ordering prefix
- AXPT4118
Wattage
- 35W
- 45W
- 54W
Voltage
- U = 120-277V
Kelvin/CCT
- 50K = 5000˚Kelvin
Finish
- DG = Dark Grey
Ordering example
AXPT4118-35W-U-50K-DG
