LED Bed Light
AXUL860
- The bed light’s design and functionality fits the needs of both patient rooms and assisted living environments. The smooth shape reduces its visual impact on the wall while simplifying the cleaning routine.
- Four position, 3 circuit pull switch (on up, on down, on both, all off) are standard and located toward the right side.
- LED nightlight and on/off pull switch is included.
Model data
| Part | Wattage | Lumens | Kelvin | Dimensions |
|---|---|---|---|---|
| AXUL860 | 72W (4x 18W) | 7,200lm | 30K; 40K; 50K | 8.125”W x 5.25”H x 48.6”L |
Specifications
| UL or ETL Listing | Damp Locations |
|---|---|
| Housing | Baked white enamel on all metal parts |
| Voltage | 120v-277v |
| Light Source | 4x LED T8 tubes (sold separately) |
| CRI | >80 |
| Kelvin | 30K, 40K, 50K |
| Mounting | Horizontal wall mount only. Power connections can be made in the fixture wiring channel or in a standard J box (not included) |
| Suggested lamps | LEDT801 • 30K • 80 CRI / LEDT804 • 40K • 80 CRI / LEDT805 • 50K • 80 CRI |
Options and ordering
Wattage
- 72W = 4x 18 watt LED T8 Tubes
Kelvin/CCT
- 30K = 3000˚Kelvin
- 40K = 4000˚Kelvin
- 50K = 5000˚Kelvin
Finish
- WH = White
Options
- PC = Pull Chain
Ordering example
AXUL860-72W-30K-WH-PC
