LED Decorative Outdoor AC/Emergency Unit
AXEM900
Model numbers
| Model | Description |
|---|---|
| AXEM900 | LED Decorative Outdoor AC/Emergency Unit |
Specifications
| Voltage | Dual 120/277 |
|---|---|
| Charge Rate / Power | “ON” LED indicator light and push-to-test switch for mandated code compliance. |
| Battery | 4.8v long-life, maintenance free, rechargeable NiCd battery. |
| Transfer Switch | Internal solid state. Automatically connects the internal battery to LED board and lamp heads for minimum 90min. emergency illumination. |
| Charger | Fully automatic, solid state, two rate charger initiates battery charging to recharge a discharged battery in 24 hrs. |
| Mounting | Universal knock-out pattern on backplate for wall mount. Threaded opening at top of enclosure for conduit mount. |
| Diagnostics | Self diagnosis feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes. |
| Photocell | Included standard for use as dusk-to- dawn luminaire. |
| Wiring | Field selectable wiring allows for AC operation of unit to be controlled using a wall switch, photocell, or other mechanism. |
Options and ordering
Housing Color
- BK = Black
- DB = Bronze
- NI = Nickel
- WH = White
Standard Feature
- SDT = Self-Diagnostics
- PC = Photocell
Options
- CW = Cold Weather
- CEC = Title 20 compliant
Ordering example
AXEM900-DB-SDT-CW
