Decorative Wall Mount
AXLEDWP782AXLEDWP784
- Ideal for entrances, walkways, rear doors, patios, multifamily, or single-family homes as well as commercial building applications.
- Photocell Included
Model data
| Part | Wattage | Lumens | CRI | Kelvin | Dimensions |
|---|---|---|---|---|---|
| AXLEDWP782 | 17w | 1,700lm | 80 | 30K, 40K | 5.48”W x 8.384”H x 3.523”Ext. |
| AXLEDWP784 | 25w | 2,200lm | 80 | 30K, 40K | 5.48”W x 8.384”H x 3.523”Ext. |
Specifications
| UL or ETL Listing | Wet Locations (IP65) |
|---|---|
| Housing | Cold Rolled Steel Baked on Enamel |
| Lens | White Acrylic Lens |
| Voltage | AC 120v |
| Light Source | 10 watt LED A19 E26 Bulb (Sold Separately) |
| Kelvin | 30K, 40K |
| Mounting | Wall Mount. All necessary hardware included. |
Options and ordering
Wattage
- 17W = 17 Watt Integrated LED
- 25W = 25 Watt Integrated LED
Kelvin/CCT
- 30K - 3000˚Kelvin
- 40K - 4000˚Kelvin
Finish
- DB = Dark Bronze
- WH = White
Ordering example
AXLEDWP782-17W-30K-DB
